تفاصيل المنتج
Place of Origin: China
اسم العلامة التجارية: MARSHINE
إصدار الشهادات: CE
Model Number: SH1040
شروط الدفع والشحن
Minimum Order Quantity: 1PC
الأسعار: usd, 300-600, pcs
Packaging Details: Wooden Box, Wooden Pallet
Delivery Time: 15-30DAY
Payment Terms: TT,LC,WESTERN UNION
Supply Ability: 200 CONTAINER/YEAR
Model NO.: |
SH1040 |
Color: |
Customize |
Application: |
Lifting Platform |
Technics: |
Welding |
Usage: |
Line Fittings |
Rated Load: |
50K-180kn |
Net Weight: |
60-330kg |
Packing: |
Bulk Pack with Wooden Board |
Sheave Features: |
Aluminum Wheel with Rubber Liner |
Transport Package: |
Carton Box |
Specification: |
50K-180kn |
Origin: |
China |
HS Code: |
8467890000 |
Supply Ability: |
20000PCS/Month |
After-sales Service: |
1 Year |
الضمان: |
سنة واحدة |
النوع: |
تركيب خط السحب |
المواد: |
إم سي نايلون |
عدد الحزم: |
3 |
التحكم: |
يدوي |
Model NO.: |
SH1040 |
Color: |
Customize |
Application: |
Lifting Platform |
Technics: |
Welding |
Usage: |
Line Fittings |
Rated Load: |
50K-180kn |
Net Weight: |
60-330kg |
Packing: |
Bulk Pack with Wooden Board |
Sheave Features: |
Aluminum Wheel with Rubber Liner |
Transport Package: |
Carton Box |
Specification: |
50K-180kn |
Origin: |
China |
HS Code: |
8467890000 |
Supply Ability: |
20000PCS/Month |
After-sales Service: |
1 Year |
الضمان: |
سنة واحدة |
النوع: |
تركيب خط السحب |
المواد: |
إم سي نايلون |
عدد الحزم: |
3 |
التحكم: |
يدوي |
1040mm Large Diameter Stringing Block With 3 Sheaves And 50K-180kn Rated Load
This 1040mm Large Diameter Stringing Block has the conductor diameter of no more than LGJ1120. That is to say, the aluminum of this conducting wire can possess the maximum cross section of 1120 square millimeters. The block dimension (outside diameter*root diameter*sheave width) is Φ1040×Φ900× 125 (mm).
Main Specifications
| Item Number | Model | Number of Sheave | Rated Load (kN) | Weight (kg) | Features |
| 10165 | SHDN1040 | 1 | 50 | 60 | MC nylon sheave |
| 10166 | SHSQN1040 | 3 | 105 | 200 | Middle: MC nylon sheave Conductor: rubber coated nylon sheave |
| 10167 | SHWQN1040 | 5 | 180 | 330 |
Notes:
1.Maximum suitable conductor ACSR1120.
2.Sheave dimension(outside diameter x root diameter x sheave width) is Ф1040 x Ф900 x 125 mm.
3.The rubber lined MC nylon sheave are completely lined,half lined sheave can be customized.
